How to disassemble Sony Vaio PCG KThe following guide will explain how to disassemble a Sony Vaio PCG K series laptop. I created this guide while taking apart a Sony Vaio PCG K2. I think you can use the following disassembly steps for all models in the PCG K line. The main reason for me to take it apart was replacing the broken power jack. Proceed disassembly on your own risk. Sony Vaio Oem Vista Iso Images' title='Sony Vaio Oem Vista Iso Images' />The following guide will explain how to disassemble a Sony Vaio PCGK series laptop. Kya Yeh Mera Pehla Pehla Pyar Hai Mp3 Free Download'>Kya Yeh Mera Pehla Pehla Pyar Hai Mp3 Free Download. I created this guide while taking apart a Sony Vaio PCGK25 model but I think you. The database recognizes 1,746,000 software titles and delivers updates for your software including minor upgrades. Before you start the disassembly process unplug the AC adapter and remove the battery. STEP 1. Carefully remove the keyboard bezel using a small flathead screwdriver. Remove it slowly, there is a flat ribbon cable connecting the power button board with the motherboard. STEP 2. Trun the bezel upside down. The red arrow pointing to the connector on the motherboard. STEP 3. Unlock the connector by lifting up the cable retainer about 1 2 millimeters. Be very careful. After the connector is unlocked, you can pull the cable and remove the bezel. STEP 4. Remove three screws from the keyboard. Dlc Quest Pc Game Download more. STEP 5. Lift up the keyboard and place it upside down on the palm rest so you an access the cable underneath. Unlock the cable connector. Disconnect the cable and remove the keyboard. Sony Vaio Oem Vista Iso Images' title='Sony Vaio Oem Vista Iso Images' />Google is compensated by these merchants. Payment is one of several factors used to rank these results. Tax and shipping costs are estimates. Windows 7, windows update ne trouve pas de mises jour aprs sa rinstallation, solution,tuto,Kb 3102810. Save-OEM.jpg' alt='Sony Vaio Oem Vista Iso Images' title='Sony Vaio Oem Vista Iso Images' />Learn about the latest consumer electronics Sony has to offer, discover features of our products and find the ones which would suit your needs. STEP 6. Remove all screws securing the metal cover. STEP 7. Remove the cover. STEP 8. After the cover has been removed, you can access and clean both cooling fans. You can clean fans with compressed air. STEP 9. Remove two screws securing the display hinges to the back side of the base. STEP 1. 0Remove four screws securing display hinges. Unplug the video cable from the motherboard. Unplug both wireless card antenna cables from the wireless card. In one of the next guides I explains how to replace LCD screen with inverter. STEP 1. 1Lift up and remove the display panel. STEP 1. 2Remove the hard drive cover, memory cover and modem cover from the bottom. Each cover is secured by one screw. STEP 1. 3Heres how you can remove the hard drive. Remove four screws securing the hard drive caddy to the base assembly. Slide the hard drive down to disconnect it from the motherboard. Lift up and remove the hard drive. STEP 1. 4Removing memory modules if needed. Carefully spread latches on both sides of slot. The memory module will pop up at 3. Pull the module from the slot by the edges. Removing modem card if needed. Remove two screws securing the modem card. Lift up the modem card to disconnect it from the motherboard and unplug cable from the side. Remove all screws from the bottom. STEP 1. 5Remove two screws securing the top cover assembly. Disconnect the touch pad cable connector on the motherboard and unplug the cable. STEP 1. 6Lift up and remove the top cover assembly. STEP 1. 7Push the CDDVD drive to the right side with your thumb. Remove the CDDVD drive. STEP 1. 8Remove three screws securing the plastic cover. STEP 1. 9Remove the cover. STEP 2. 0The power jack is hidden under the metal bracket. Remove one screw securing the bracket. STEP 2. 1Lift up the bracket. Now you can access the power jack. Release the power jack. Now you can remove the broken power jack unsolder from the harness and replace it with a new one. You can support my work It takes hours to create one disassembly guide and only a minute to donate.
